2004 RCM-1 Continental Steam Flow Can Seamer

The machine is set on 211 can size steam flow.

• Technical Specifications: 2000 RCM	2003 3-Spindle	2004 4 -Spindle	2006 6-Spindle
  Maximum Speed (dependent on can size, type, and type of drive)	300 CPM	400 CPM	600 CPM
  Diameter range of cans handled	211-610*	202-408*	202-404*
  Height range of cans handled with standard tin line	208-910	110-800**	110-910**
  Single Horizontal Chain Pitch	10.336	6.46	5.168
  Dual (vertical/horizontal) Chain Pitch	9.75	6.000 or 6.375	4.875 or 5.250
  Net weight, approximate lbs/kg	5100 lbs/2315 kg	5150 lbs/2335 kg	5200 lbs/2360 kg
  Height max	87.6”/222.5 cm	86”/218.4 cm	86”/218.4 cm
  Width	54.0”/137.0 cm	54.0”/137.0 cm	54.0”/137.0 cm
  Length, basic	74.2”/188.5 cm	4.2”/188.5 cm	4.2”/188.5 cm
